HUBMAX 2.5 Ton Electric Stacker
The HUBMAX 2.5 Ton Electric Stacker is built for heavy-duty warehouse applications demanding stable lifting, long operating cycles, and high pallet stacking up to 6.5 meters. With a rigid industrial chassis and high-power AC drive system, this model handles large pallet loads with controlled precision. Available in Li-ion and semi-electric variants
HUBMAX Electric Forklifts
HUBMAX 2.5 Ton Electric Stacker
Delivering powerful lift performance, precise control, and exceptional stability in narrow aisles
Key Highlights:
✓ Intelligent Safety & Stability
✓ High-Efficiency Ac Drive system
✓ Lead-acid & Li-ion fast-charging options
✓ Low Maintenance & easy service
✓ Order to Build, Strokes Customizable
HUBMAX Reach Trucks are engineered for high-density warehouse operations in India, delivering powerful lift performance, precise control, and exceptional stability in narrow aisles. Our reach truck range includes 1.5 Ton, 2.0 Ton, and 2.5 Ton models powered by Li-Ion and Lead-Acid batteries ideal for electric reach truck applications, multi-shift workloads, and demanding warehouse environments.
HUBMAX 2.5 Ton Electric Stacker India
The 2.5 ton electric stacker India model is widely preferred for large warehouses, cold storage units, manufacturing plants, and high-volume pallet handling operations where stability and continuous performance are critical. Choose a Li-ion stacker India for fast charging, zero maintenance, and multi-shift productivity, or opt for a semi-electric stacker India for cost-efficient heavy-duty material handling. As a leading electric stacker manufacturer India, HUBMAX ensures the 2.5T stacker delivers superior load stability, clear operator visibility, smooth lifting control, and consistent performance in stacker for narrow aisle India warehouse environments
Reinforced Pantograph & Stability
Heavy-duty pantograph reach with precision rollers and reinforced guide bearings ensures safe two-deep access.
Cold Storage Ready
Li-ion battery options and sealed components for reliable performance in low-temperature environments.
Ideal for 3PL & FMCG
Designed to handle rapid pallet throughput and variable SKU density typical of distribution centers.
Gain 25–35% More Storage
Store two pallets deep to increase usable storage without expanding your warehouse footprint.
Reduce Aisle Width & Boost Throughput
Optimised for narrow aisles — fewer travel cycles and faster pallet turns.
Lower Cost per Pallet Position
Higher density reduces overall racking and facility costs per pallet position.
Electric Stacker 2.5T Specifications & Features
Compare the HUBMAX 2.5T Electric Stacker with Li-ion and Lead-Acid battery options to deliver smooth, efficient, and reliable performance for light-to-medium pallet handling and low-to-mid height storage operations
HUB-ES25 -- 2.5 Ton Electric Stacker Key Specification and features
Specification | ㅤ |
|---|---|
Capacity | 2,500 kg |
Lift Height | 3.0–6.5 m |
Mast | Duplex / Triplex / Quad |
Battery | 24V / 400–500 Ah (Li-ion preferred for high-lift) |
Drive Motor | 9.0 kW AC |
Lift Motor | 4.5 kW |
Service Weight | ~1,150 kg |
Mast Rail | U-Channel 140×50 mm |
Turning Radius | 1,350 mm |
Hydraulic Pressure | 220 bar |
Performance | ㅤ |
|---|---|
Battery | 24V / 210–300 Ah (Lead Acid or Li-ion LFP)
(Higher Ah available on request) |
Charger | Offboard (std.) / Onboard (optional) |
Controller | ZAPI / Curtis |
Drive & Hydraulics | ㅤ |
|---|---|
Lift Motor | AC Hydraulic 3.0 – 3.5 kW |
Hydraulic Pump Brand | Bosch Rexroth / Parker |
Hydraulic Pressure | 180–190 bar |
Oil Flow | 40 L/min |
Drive Motor | AC Brushless PMSM |
Drive Motor Power | 5.5 – 6.5 kW |
Electrical & Controls | ㅤ |
|---|---|
Battery | 24V / 210–300 Ah (Lead Acid or Li-ion LFP)
(Higher Ah available on request) |
Charger | Offboard (std.) / Onboard (optional) |
Controller | ZAPI / Curtis |
Operator Safety & Comfort |
|---|
Emergency reverse belly button |
Auto speed control in cornering |
Anti-rollback on slopes |
Overload protection |
Emergency stop switch |
OPS (Operator Presence System) |
Option |
|---|
Side-pull battery |
Triplex free-lift mast |
Li-ion battery pack |
Fast charger |
EPS (Electronic Power Steering) |
