HUBMAX 2.5 Ton Double Deep Reach Truck
HUBMAX Reach Trucks are engineered for high-density warehouse operations in India, delivering powerful lift performance, precise control, and exceptional stability in narrow aisles. Our reach truck range includes 1.5 Ton, 2.0 Ton, and 2.5 Ton models powered by Li-Ion and Lead-Acid batteries—ideal for electric reach truck applications, multi-shift workloads, and demanding warehouse environments.
The HUBMAX 2.5 Ton Double Deep Reach Truck is a heavy-duty warehouse solution designed for high-load capacity, deep-rack storage systems, and high-lift performance in demanding logistics environments. Equipped with a reinforced industrial pantograph mechanism, heavy-duty triplex mast, high-capacity AC drive motor, and precision hydraulic system, this advanced double deep reach truck enables operators to handle and position heavy pallets in double-deep racking with superior stability, accuracy, and safety.
HUBMAX 2.5 Ton Double Deep Reach Truck
Reinforced pantograph mechanism, high-rigidity triplex mast, advanced AC drive motor
Key Highlights:
✓ High-Efficiency Ac Drive system
✓ Advanced Safety & stability assist
✓ Lead-acid & Li-ion fast-charging options
✓ Low Maintenance & easy service
✓ Order to Build, Strokes Customizable
Top things to know about 2.5 Ton HUBMAX Double Deep Reach Truck
Essential specifications, operating advantages, and application details for informed equipment selection

Long-Shift Li-Ion & Lead-Acid Power
Efficient working hours with low maintenance.

Long-Shift Li-Ion & Lead-Acid Power
Efficient battery options support extended working hours with low maintenance.

Long-Shift Li-Ion & Lead-Acid Power
Efficient battery options support extended working hours with low maintenance.

Long-Shift Li-Ion & Lead-Acid Power
Efficient battery options support extended working hours with low maintenance.
.avif)
Stable High-Lift Perform up to 11 Meters
Equipped with a reinforced mast and anti-sway system, the 2.5T variant provides excellent stability

Designed for High-Density Storage Layouts
The 2.5T DDR is ideal for warehouses where increasing pallet positions is a priority

Long-Shift Li-Ion & Lead-Acid Power
The heavy-duty pantograph mechanism offers stable extension and retraction even under load

Energy-Efficient AC Drive System
HUBMAX Double Deep Reach Truck The AC drive motor ensures consistent travel speed, energy efficiency
Download Section
Access technical documentation and resources
Detailed technical specifications Sheet for This HUBMAX models and configurations Download from below button
Comprehensive safety procedures and maintenance guidelines for HUBMAX equipment
HUBMAX 2.5 Ton Double Deep Reach Truck
The HUBMAX 2.5 Ton Double Deep Reach Truck is a heavy-duty warehouse solution designed for high-load capacity, deep-rack storage systems, and high-lift performance in demanding logistics environments. Equipped with a reinforced industrial pantograph mechanism, heavy-duty triplex mast, high-capacity AC drive motor, and precision hydraulic system, this advanced double deep reach truck enables operators to handle and position heavy pallets in double-deep racking with superior stability, accuracy, and safety.
HUBMAX Electric Forklifts
HUBMAX 2.5 Ton Double Deep Reach Truck
Reinforced pantograph mechanism, high-rigidity triplex mast, advanced AC drive motor
Key Highlights:
✓ High-Efficiency Ac Drive system
✓ Advanced Safety & stability assist
✓ Lead-acid & Li-ion fast-charging options
✓ Low Maintenance & easy service
✓ Order to Build, Strokes Customizable
HUBMAX Reach Trucks are engineered for high-density warehouse operations in India, delivering powerful lift performance, precise control, and exceptional stability in narrow aisles. Our reach truck range includes 1.5 Ton, 2.0 Ton, and 2.5 Ton models powered by Li-Ion and Lead-Acid batteries ideal for electric reach truck applications, multi-shift workloads, and demanding warehouse environments.
HUBMAX 2.5 Ton Double Deep Reach Truck India
The HUBMAX 2.5 Ton Double Deep Reach Truck India variant is engineered for high-performance Indian warehouses handling heavy pallet loads, intensive stacking cycles, and deep-rack storage systems, where maximum space utilization and operational efficiency are critical. With a pantograph reach of up to 1100mm and lift heights up to 11 meters, this advanced double deep reach truck enables businesses to fully optimize cubic storage space, increase pallet density, and eliminate the need for warehouse expansion. Designed for high-density logistics environments, it ensures smooth, stable, and precise pallet handling in double-deep racking, making it ideal for FMCG warehouses, e-commerce fulfillment centers, industrial storage facilities, and cold chain logistics across India. The Li-ion DDR India variant supports fast charging, opportunity charging, and zero-maintenance operation, making it perfect for continuous multi-shift usage and high-throughput operations, while the lead-acid DDR India option provides a cost-effective solution for structured single- or double-shift warehouse environments. As a leading double deep reach truck manufacturer in India, HUBMAX delivers machines built for real-world reliability, ensuring consistent performance in dusty conditions, temperature-controlled warehouses, and demanding industrial applications. With robust engineering, energy-efficient performance, and ergonomic control systems, the HUBMAX 2.5 Ton DDR offers a scalable, cost-efficient, and productivity-driven solution for modern Indian warehousing and logistics operations.
Gain 25–35% More Storage
Store two pallets deep to increase usable storage without expanding your warehouse footprint.
Reduce Aisle Width & Boost Throughput
Optimised for narrow aisles — fewer travel cycles and faster pallet turns.
Lower Cost per Pallet Position
Higher density reduces overall racking and facility costs per pallet position.
Reinforced Pantograph & Stability
Heavy-duty pantograph reach with precision rollers and reinforced guide bearings ensures safe two-deep access.
Cold Storage Ready
Li-ion battery options and sealed components for reliable performance in low-temperature environments.
Ideal for 3PL & FMCG
Designed to handle rapid pallet throughput and variable SKU density typical of distribution centers.
HUBMAX Double Deep Reach Truck 2.5T Specifications & Features
Compare the HUBMAX 2.5T Double Deep reach truck with Li-Ion and Lead-Acid options to achieve smooth, efficient, and reliable performance for light-to-medium pallet handling and mid-level storage operations.
HUB-DDRT25 -- 2.5 Ton Double Deep Reach Truck Key Specification and Features
Specification | ㅤ |
|---|---|
Rated Capacity | 2,500 kg |
Lift Heights | 7 / 9 / 11 m |
Pantograph Reach | 1,050–1,100 mm |
Aisle Width | ~2,200 mm |
Turning Radius | 1,600 mm |
Battery | 48V / 600–700 Ah |
Service Weight | 4,200–4,600 kg |
Performance | ㅤ |
|---|---|
Lift Speed (L/U) | 0.24 / 0.28 m/s |
Gradeability | 14–18% |
Braking | Regenerative + electromagnetic |
Travel Speed | 12–14 km/h |
Drive & Hydraulics | ㅤ |
|---|---|
Lift Motor | AC 12–14 kW |
Hydraulic Pressure | 270–280 bar |
Hydraulic Flow | High-flow industrial |
Pantograph Assembly | Extra-reinforced arms + guide bearings |
Drive Motor | AC 16–18 kW |
Electrical & Controls | ㅤ |
|---|---|
Battery Options | Lead-acid / Li-ion LFP |
Charger | Fast charger optional |
Controller | ZAPI AC Heavy Duty |
Operator Safety & Comfort |
|---|
Speed limiting in tight turns |
Load stability monitoring |
Safety operator cage |
Adjustable suspension seat |
High-visibility mast |
Ideal Application |
|---|
Cold storage (Li-ion ideal) |
Heavy load double-deep warehouses |
High-capacity storage |
USP Feature | ㅤ |
|---|---|
Longest Reach Stroke | Extended pantograph stroke (1000–1200 mm) for deep-lane access. |
Industrial Mast Stability | High-rigidity structure ensures balance at 11m lift height. |
High-Capacity Li-ion Power | Supports up to 420Ah Li-ion for multi-shift heavy operations. |
Reinforced Chassis | Built for rugged 24/7 warehouse duty across heavy-load operations. |
Fast, Efficient Hydraulics | Smooth, responsive reach-in/out cycles for faster pallet movement. |
Suitable For | Distribution centres, pharma, heavy logistics, dense pallet storage. |
Maximum Lifting Capacity | Handles 2.5 Ton loads for heavy-duty industrial applications. |
